Field Remedy: 1731
| Subject: | Diesel Engine - Booming Noise |
|---|
| Models: | Engines: | Option: |
|---|---|---|
| Astra-H 2004...,Zafira-B 2005... | Z17DTH| Z17DTL,Z19DTL| Z19DT| Z19DTH| Z19DTJ | with DPF,w/o DPF |
| Complaint: | Booming noise between 1700 and 1900 1/min |
|---|---|
| Cause: | |
| Production: | The dampers have been introduced in production for all Z17DTx engines (engines with diesel particle filter and engines without diesel particle filter) as of VIN: Plant Bochum: W0L0AHL3552160708; Plant Antwerpen: W0L0AHL4855170016; Plant Ellesmere Port: W0L0AHL4858109060. The dampers have been introduced in production for all Z19DTx engines (engines with diesel particle filter and engines without diesel particle filter) as of VIN: Plant Bochum: W0L0AHM7562084370; Plant Antwerpen: W0L0AHL0765086005; Plant Ellesmere Port: W0L0AHL4868059380; Plant Gleiwitz: W0L0AHM756G049243. |
Remedy:
In case of customer complaint install a damper to the sub frame.
Working procedure:
1. Remove screw of rear damping block (Picture I, 1)
2. Install damper (2) with screw (1) to the sub frame (Picture II).
Note:
- tightening torque 55 Nm
Spare-Parts: Part-No.: Catalogue-No.:
Kit, Damper, Assy., Vibration, 24459603 3 02 055 Drive Shaft
Labour Times: TC: Hours:
U3 173 10 Install damper to 90 0.1 sub frame
001 Additional work at 90 0.2 vehicles with lower engine cover
The costs for this repair will be covered for vehicles not older than 3 years and a mileage lower than 100.000 Km. The regular warranty procedure should be used for claiming Set-up-time.
| FunctionalGroup: | J - Engine |
|---|---|
| Complaint Group: | 14 - Noises or Vibrations |
| Trouble Code: | None |
