Field Remedy: 1860
| Subject: | Meriva Engine Z17DT/DTH - Extension fuel filler for fuel tank |
|---|
| Models: | Engines: | Option: |
|---|---|---|
| Meriva 2003... | Z17DTH| Z17DTL | None |
| Complaint: | After stopping of the dispensing pump it may happen that fuel squirts out of the filler neck depending on certain banking positions of the vehicle. |
|---|---|
| Cause: | Overpressure in fuel tank due to insufficient ventilation over the filler neck. |
| Production: | Extensions into filler neck of fuel tank have been introduced in produktion as of VIN W0L0XCE7554395331. |
Remedy:
In case of customer complaint install an extension into the filler neck of fuel tank.
Warning: Observe safety regulations and national legislation!
Important: The fuel tank must be filled maximum for a quarter.
Working Procedure:
1. Remove fuel filler hose from fuel tank (Picture I, 1).
- place basin underneath - loosen clamp (2)
2. Install extension into the filler neck of fuel tank (Picture II, 1).
- apply extension into fuel tank Note: The notch (arrow) must show towards the middle of the top. - drive-in extension up to the stop
3. Check extension for correct fitting (Picture III, 1).
- extension must fit flush into the filler neck of fuel tank - the notch must show towards the middle of the top
4. Install fuel filler hose to fuel tank.
- tighten clamp
Spare-Parts: Part-No.: Catalogue-No.:
Extension Fuel Filler 13216016 90 08 013
Labour Times: TC: Hours:
U3 186 00 Install an extension into 90 0.2 fuel filler neck
The costs for this action will be covered during the normal warranty. The regular warranty procedure should be used for claiming Set-up-time.
| FunctionalGroup: | L - Fuel- and Exhaust System |
|---|---|
| Complaint Group: | 08 - Hard to operate |
| Trouble Code: | None |
