Field Remedy: 1706
| Subject: | Engine Z16XEP - Pulsation noise from fuel feed pipe |
|---|
| Models: | Engines: | Option: |
|---|---|---|
| Astra-G 2003...2004 | Z16XEP |
| Complaint: | Knocking-/ pulsation noise from bulk head area. |
|---|---|
| Cause: | Noise occurs due to pulsation of fuel column in feed pipe. |
| Production: |
Remedy:
In case of customer complaint install a surge tank.
Procedure:
1. Detach the fuel feed pipe from distributor see picture I, 1.
2. Cut the fuel feed pipe see picture II, X (X approx. 45 mm).
3. Cut fuel feed pipe (tank side) by approx. 50 mm to compensate the dimension of surge tank. 4. Pre-fit the clamps on fuel feed pipes as shown in picture II, 1. 5. Insert the surge tank into the fuel feed pipe as shown in picture II, 2.
Note: Ensure free travel of surge tank and clips.
6. Position the clamps as shown in picture II, 1 and detach "pull-off-clip" from clamp. 7. Connect fuel feed pipe to distributor.
Spare Parts: Qty.: Part-No.: Cataloge-No.:
Surge Tank, Header, Distributor 1 90528569 08 06 431 to fuel feed pipe Clamp, Hose, Fuel 2 24445245 08 24 294
| FunctionalGroup: | L - Fuel- and Exhaust System |
|---|---|
| Complaint Group: | 14 - Noises or Vibrations |
| Trouble Code: | None |
