Headlamps with xenon low beam technology are available as optional equipment. The xenon light road illumination (gas discharge lamp), which is similar to daylight, corresponds to our natural vision and therefore permits driving conditions which are less tiring and more relaxed than with conventional headlamp systems. Constant illumination is provided in all driving situations through the integrated automatic headlamp range control and the high-pressure washer system.
The headlamp system with xenon low beam consists of the following components:
- Ellipsoidal headlamps with xenon lamps for low beam (type D2S) and xenon control unit
- High beam with H7 halogen single-filament bulb
- Automatic range control (sensor between rear axle and vehicle underbody)
- High-pressure washer system
Survey of headlamp, front side
| 1 | Turn signal lamp | 3 | H7 halogen single-filament bulb for high beam |
|---|---|---|---|
| 2 | Xenon low beam | 4 | Parking lamp |
• Service: Vehicles with standard H7 halogen headlamps cannot be retrofitted with xenon low beam headlamps.
Survey of headlamp, rear side
| 1 | Turn signal lamp | 4 | Parking lamp |
|---|---|---|---|
| 2 | Xenon low beam with ignition module | 5 | Servo motor for headlamp range control |
| 3 | High beam | 6 | Control unit, xenon |
