Field Remedy: 1514
| Subject: | Backrest hinge of rear seat - Rattling noise |
|---|
| Models: | Engines: | Option: |
|---|---|---|
| Vectra-C 2002 | All | Notchback,Hatchback |
| Complaint: | Rattling noise out of rear seat backrest hinge while driving. |
|---|---|
| Cause: | Clearance of hinge alignment. |
| Production: | As of VIN: W0L0ZCF6921080574 for Rüsselsheim and VIN: W0L0ZCF6828107876 for Ellesmere Port new parts have been introduced in production. |
Remedy:
In case of customer complaint replace bearing discs backrest hinge of rear seat.
1. Remove rear backrest left and right
- see working procedure "Rear Backrest – Left, Remove and Install" and "Rear Backrest – Right, Remove and Install", group "C", Service Instruction Vectra-C.
2. Remove bearing nut of rear backrest hinge (Picture I).
3. Replace bearing disc (Picture II, arrow).
4. Install bearing nut rear backrest hinge – torque 23 Nm. 5. Install rear backrest left and right
- see working procedure "Rear Backrest – Left, Remove and Install" and "Rear Backrest – Right, Remove and Install", group "C", Service Instruction Vectra-C.
Spare-Parts: Part-No.: Catalog-No.:
2x Bearing disc, rear backrest 13122620 51 68 625
Labour Times: TC: Hours:
T 8 151 40 Replace bearing 92 0.3 disc of rear backrest
The costs for this repair will be covered for vehicles not older than 3 years. The regular warranty procedure should be used for claiming Set-up-time.
| FunctionalGroup: | C - Equipment/Windows/Seats |
|---|---|
| Complaint Group: | 02 - Chafing,14 - Noises or Vibrations |
| Trouble Code: |
