Field Remedy: 1741
| Subject: | Alloy rim "Riviera Edition" - Vibration during driving |
|---|
| Models: | Engines: | Option: |
|---|---|---|
| Agila 2004 | All |
| Complaint: | During driving strong vibrations are noticeable. |
|---|---|
| Cause: | Diameter of center hole is to large, centering of rim is not possible. |
| Production: | As of VIN W0L0HAF684G048311 for gasoline engines and VIN W0L0HAF684G049047 for diesel engines new improved alloy rims have been introduced in production. |
Remedy:
In case of customer complaint a special center ring has to be installed at center hole of the alloy rim. The special center rings can be ordered via parts and accessories, Partnumber: 13204059 / Catalognumber: 47 08 000.
Picture I (arrow) shows the alloy rim without special center ring.
Picture II shows the alloy rim with installed special center ring. The special center ring (1) has to be engaged at center hole of the alloy rim as shown in picture II (arrows).
| FunctionalGroup: | E - Front wheel suspension/Wheels/Tyres |
|---|---|
| Complaint Group: | 14 - Noises or Vibrations |
| Trouble Code: | None |
