Field Remedy: 1234
| Subject: | Rear door striker bolt - Welding spots cracked |
|---|
| Models: | Engines: | Option: |
|---|---|---|
| Vectra-B 1996...1998,Zafira 1999...2002 | All,All |
| Complaint: | Circular cracks in the area of the spot welds, on the door frame C-pillar in the area of the striker assembly. |
|---|---|
| Cause: | Load at higher body-tension. |
| Production: | For Zafira improvements have been implemented in production as of VIN W0L0TGF7522007115. |
Remedy:
In case of customer complaint drill out cracks/spots welds and fill with weld metal.
The job is described for 1 C-pillar. The work applies correspondingly to the second C-pillar. If both C-pillars of the vehicle should be subject to the identical operating conditions, it must be decided depending on the situation whether all spot welds including those not cracked are optimised.
The picture shows the area of the striker assembly.
Working Procedure:
Disconnect battery.
Remove interior trim C-pillar
- see working procedure "Interior trim C/D-pillar remove and install", group "C", of the corresponding Service Instruction.
Remove seat belt
- see working procedure "Seat belt rear/C-pillar remove and install", group "C", of the corresponding Service Instruction.
Remove striker assembly.
Centre punch spot welds.
Drill or mill spot welds on the upper metal plate using an 8 mm cutter, do not damage the metal plate below.
Guard against flying sparkes.
Grind/ sand the repair area.
Fill up bore holes with weld metal.
Grind/sand weld points smooth.
Repaint the repair area.
Seal body cavity.
Install seat belt
- see working procedure "Seat belt rear/C-pillar remove and install", group "C", of the corresponding Service Instruction.
Install interior trim C-pillar
- see working procedure "Interior trim C/D-pillar remove and install", group "C", of the corresponding Service Instruction.
Connect battery and program all fleeting memories.
For further information about corrosion protection and enamel repair refer to TIS 2000 Service Information.
Labour-operation: Caravan: TC: Hours:
T 8123 40 Repair of one C-pillar 92 1.3 hrs 002 Single coat paint 1.8 hrs +: Vehicle availability for paint 001 Additional labour for 0.1 hrs vehicles with twin coat paint
T 8123 41 Repair of both C-pillars 92 2.4 hrs 002 Single coat paint 2.6 hrs +: Vehicle availibility for paint 001 Additional labour for 0.2 hrs vehicles with twin coat paint
Notchback:
T 8123 42 Repair of one C-pillar 92 1.1 hrs 002 Single coat paint 1.8 hrs +: Vehicle availibility for paint 001 Additional labour for 0.1 hrs vehicles with twin coat paint
T 8123 43 Repair of both C-pillars 92 2.2 hrs 002 Single coat paint 2.6 hrs +: Vehicle availibility for paint 001 Additional labour for 0.2 hrs vehicles with twin coat paint
Hatchback:
T 8123 44 Repair of one C-pillar 92 1.2 hrs 002 Single coat paint 1.8 hrs +: Vehicle availibility for paint 001 Additional labour for 0.1 hrs vehicles with twin coat paint
T 8123 45 Repair of both C-pillars 92 2.2 hrs 002 Single coat paint 2.6 hrs +: Vehicle availibility for paint 001 Additional labour for 0.2 hrs vehicles with twin coat paint
Zafira :
T 8123 46 Repair of one C-pillar 92 1.1 hrs 002 Single coat paint 1.8 hrs +: Vehicle availibility for paint 001 Additional labour for 0.1 hrs vehicles with twin coat paint
T 8123 47 Repair of both C-pillars 92 2.1 hrs 002 Single coat paint 2.6 hrs +: Vehicle availibility for paint 001 Additional labour for 0.2 hrs vehicles with twin coat paint
The regular warranty procedure should be used for claiming Set-up-time
| FunctionalGroup: | A - Body |
|---|---|
| Complaint Group: | 01 - Broken or Cracked |
| Trouble Code: | Non |
