Распиновка разъёма A59 Opel Vivaro A

Войти

Контакты разъёма: B4<br>Not occupied, B3<br>Not occupied, C3<br>B24 Sensor - Vehicle speed<br>Terminal B1<br>(Vehicle speed signal)<br>..., D3<br>Y11 Throttle valve - Positioner<br>Terminal 6<br>(Sensor signal), E3<br>B13 Sensor - Temperature, intake air<br>Terminal 2<br>(Sensor signal), E1<br>Not occupied, D1<br>Not occupied, E2<br>B13 Sensor - Temperature, intake air<br>Terminal 1<br>(Sensor(s) voltage s..., D2<br>Not occupied, C1<br>Not occupied, C2<br> Sensor - Knock control 1<br>Terminal -<br>(Sensor ground), E4<br>B34 Impulse sensor - Crankshaft<br>Terminal 2<br>(Sensor ground), D4<br>K18 Relay - Engine control unit<br>Terminal D2<br>(Control signal), C4<br>B58 Switch - Pressure, power steering<br>Terminal 1<br>(Switch signal), A2<br>B30 Sensor - Knock control 1<br>Terminal 2<br>(Sensor signal), B1<br>Not occupied, A1<br>Not occupied, B2<br>B30 Sensor - Knock control 1<br>Terminal 1<br>(Sensor ground), A3<br>Not occupied, A4<br>FB4 Fuse<br>Terminal -<br>(Ignition voltage), F1<br>Not occupied, F2<br>B12 Sensor - Coolant temperature<br>Terminal B2<br>(Sensor signal), F3<br>B34 Impulse sensor - Crankshaft<br>Terminal 1<br>(Sensor signal), F4<br>B12 Sensor - Coolant temperature<br>Terminal B1<br>(Sensor ground), G1<br>Not occupied, G2<br>Y11 Throttle valve - Positioner<br>Terminal 5<br>(Sensor(s) voltage supply..., G3<br>Y11 Throttle valve - Positioner<br>Terminal 2<br>(Sensor signal), G4<br>Y11 Throttle valve - Positioner<br>Terminal 1<br>(Sensor ground), H1<br>Not occupied, H2<br>B29 Sensor - Pressure, air conditioning<br>Terminal B<br>(Sensor(s) voltag..., H3<br>B110 Sensor - Atmospheric pressure<br>Terminal B<br>(Sensor signal), H4<br>B29 Sensor - Pressure, air conditioning<br>Terminal A<br>(Sensor ground)..., J1<br>Not occupied, J2<br>Not occupied, J3<br>B29 Sensor - Pressure, air conditioning<br>Terminal C2<br>(Sensor signal), J4<br>Not occupied, K1<br>Not occupied, K2<br>Not occupied, K3<br>Not occupied, K4<br>Not occupied, L1<br>Not occupied, L2<br>Y9.3 Injection valve - Cylinder 3<br>Terminal 2<br>(Control signal), L3<br>Y9.2 Injection valve - Cylinder 2<br>Terminal 2<br>(Control signal), L4<br>Y9.1 Injection valve - Cylinder 1<br>Terminal 2<br>(Control signal), M1<br>Not occupied, M2<br>Y9.4 Injection valve - Cylinder 4<br>Terminal 2<br>(Control signal), M3<br>Y11 Throttle valve - Positioner<br>Terminal 3<br>(Control signal), M4<br>Y11 Throttle valve - Positioner<br>Terminal 4<br>(Actuator(s) voltage supp...
