Распиновка разъёма A29 Opel Vivaro A

Войти

Контакты разъёма: 1<br>FC12 Fuse<br>Terminal -<br>(Constant voltage supply (30)), 11<br>Not occupied, 2<br>H1 Instrument<br>Terminal 20 (X35)<br>(Control signal), 12<br>S87 Switch - Central locking (instrument)<br>Terminal B3<br>(Control signa..., 13<br>S87 Switch - Central locking (instrument)<br>Terminal B1<br>(Switch signal..., 3<br>K3 Relay - Heated back window<br>Terminal A2<br>(Control signal)<br><br>S70..., 4<br>S70 Switch - Heated back window<br>Terminal B1<br>(Switch signal), 14<br>S87 Switch - Central locking (instrument)<br>Terminal A3<br>(Switch signal..., 5<br>Not occupied, 15<br>E16 Lamp unit - Passenger compartment, time delay<br>Terminal 1 (X64)<br>(..., 16<br>B47 Signal horn - Anti-theft warning system<br>Terminal B<br>(Control sign..., 6<br>S3 Switch unit - Steering column<br>Terminal A5 (X65)<br>(Switch signal, Tu..., 7<br>S3 Switch unit - Steering column<br>Terminal A7 (X65)<br>(Switch signal, Tu..., 17<br>S16 Switch - Engine hood, anti-theft warning system<br>Terminal A<br>(Swit..., 8<br>A1 Control unit - Airbag<br>Terminal 58<br>(High Speed CAN-bus), 18<br> Switch - Engine hood, anti-theft warning system<br>Terminal -<br>(High Sp..., 19<br>Not occupied, 9<br>Not occupied, 10<br>A1 Control unit - Airbag<br>Terminal 59<br>(High Speed CAN-bus), 20<br> Switch - Engine hood, anti-theft warning system<br>Terminal -<br>(High Sp..., 21<br>S6 Switch - Hazard light<br>Terminal 4<br>(Control signal), 31<br>Not occupied, 22<br>U3 Receiver - Immobiliser<br>Terminal 4<br>(Signal input), 32<br>Not occupied, 23<br> Receiver - Immobiliser<br>Terminal 1<br>(Switch signal, Door contact swit..., 33<br>FC16 Fuse<br>Terminal -<br>(Ignition voltage), 24<br>S22 Switch - Wiper unit<br>Terminal A4<br>(Switch signal, Washer), 34<br>Not occupied, 25<br>S22 Switch - Wiper unit<br>Terminal A1<br>(Switch signal, Wiper windscreen..., 35<br>Not occupied, 26<br>FC31 Fuse<br>Terminal -<br>(Switch signal), 36<br>S6 Switch - Hazard light<br>Terminal 3<br>(Switch signal), 27<br>S38 Contact switch - Driver door<br>Terminal A<br>(Switch signal)<br><br>S..., 37<br>Not occupied, 28<br>Not occupied, 38<br>Not occupied, 29<br>Not occupied, 39<br>Not occupied, 30<br>Not occupied, 40<br>X13 Diagnostic link<br>Terminal 7<br>(Data Line)
