Battery Positive Lead - Non Replaceable Fusible Link (FLB) Opel Vivaro A

Field Remedy: 1909

Remedy:

In case of customer complaint replace the original fusible link (FLB) with a new service replacement. The original is soldered into the main harness so the following proceedure should be followed. NO attempt should be made to repair the original fuse once blown.

1. Disconnect battery negative lead

2. Disconnect battery positive lead

3. Release battery positive harness from battery compartment • Release clip (1)

Войти

4. Remove heat shrink from positive lead • Cut off using suitable tool

5. Remove fusible link from positive lead • Cut off using suitable tool Note: Cut the positive lead as close as possible to the fusible link

Войти

6. Install new fusible link to positive lead • Remove approximately 20 mm of insulation from positive lead • Cut off using suitable tool • Position new heat shrink; do not apply heat at this stage • Crimp cable with fusible link • Use suitable crimping tool • Secure heat shrink • Apply heat using suitable tool and shrink

Войти

7. Secure battery positive harness to battery compartment • Secure clip (1)

Войти

8. Connect battery positive lead

9. Connect battery negative lead

10. Program all volatile memories

Please note that the above service operations will be included in TIS 2000-CD65 - August 05 (English language) and TIS 200-CD66 - September 05 (other languages). The Part-No. / Catalogue-No. (350A Fuse Petrol) will be published when parts are available.

Spare-Parts: Part-No.: Catalogue-No.:

400A Fuse Diesel 93 187 215 44 16 388 350A Fuse Petrol 93 188 393 44 16 486

Labour Times: TC: Hours:

U3 190 90 Replace Fuse Terminal 90 0,4

The costs for this action will be covered during the normal warranty. The regular warranty procedure should be used for claiming Set-up-time.
