A cold climate package is available for some territories and consists of:

  • Rear disc brake protector
  • Insulated engine breather hose
  • Strength of screen wash mixture increased from 20% to 45%
  • Strength of antifreeze mixture for increased protection down to -40°C
  • Power steering fluid changed to Mobil Fully Synthetic ATF
Rear Disc Brake Protector

The rear disc brake protector (1) is secured to the stub axle by means of bolts.

Insulated Breather Hose for F9Q 774 Engine

The insulated breather hose (1) is located between the oil separator (3) and the air intake hose for the turbochager (4). The oil separator is adjacent to the engine oil filler cap (2).

Insulated Breather Hose for G9T 750, G9U 750 and G9U 754 Engines

The insulated breather hose (1) is located between the cylinder head cover (2) and the air intake hose (4) for the turbocharger (3).
